ALL PRODUCTS
|
|
1. DB-202 [2006年9月23日]
 | | | Brand：Harman/Amplifier/db Series |
Nominal impedance：10KΩ-20KΩ
Frequency response：20Hz-20KHz
Sensitivity：1V
S/N(wide Band Width)：≥90dB
IMD(rated power)：≤0.05%
Output 8Ω：350W×2
Max 4Ω：600W×2
Power Bridge 8Ω：1200W
Power：220V 50-60Hz
Shipping Size：560×530×180mm
Net Weight：20.5Kg |
|
2. B-5000 [2006年9月23日]
 | | | Brand：Harman/Amplifier/B Series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：1V
S/N(wide Band Width)：≥95dB
IMD(rated power)：≤0.05%
Output 8Ω：1000W×2
Max 4Ω：1500W×2
Power Bridge 8Ω：3000W
Power：220-240V 50-60Hz
Shipping Size：600×525×215mm
Net Weight：37Kg |
|
3. B-4000 [2006年9月23日]
 | | | Brand：Harman/Amplifier/B Series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-10Hz
Sensitivity：1V
S/N(wide Band Width)：≥95dB
IMD(rated power)：≤0.05%
Output 8Ω：800W×2
Max Ω4：1200W×2
Power Bridge 8Ω：2400W
Power：220-240V 50-60Hz
Shipping Size：600×525×215mm
Net Weight：34Kg |
|
4. B-3000 [2006年9月23日]
 | | | Brand：Harman/Amplifier/B Series |
Nominal impedance：20KΩ-10Ω
Frequency response：20Hz-10KHz
Sensitivity：1V
S/N(wide Band Width)：≥90dB
IMD(rated power)：≤0.05%
Output 8Ω：500W×2
Max 4Ω：800W×2
Power Bridge 8Ω：1600W
Power：220-240V 50-60Hz
Shipping Size：560×530×180mm
Net Weight：22.5Kg |
|
5. B-2000 [2006年9月23日]
 | | | Brand：Harman/Amplifier/B Series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：1V
S/N(wide Band Width)：≥90dB
IMD(rated power)：≤0.05%
Output 8Ω：350W×2
Max 4Ω：600W×2
Power Bridge 8Ω：1200W
Power：220V-240V 50-60Hz
Shipping Size：560×530×180mm
Net Weight：20.5Kg |
|
6. BH-503 [2006年9月23日]
 | | | Brand：Harman/Amplifier/BH Series |
Nominal impedance：10KΩ-20KΩ
Frequency response：20Hz-20KHz
Sensitivity：1V
S/N(wide Band Width)：≥95dB
IMD(rated power)：0.05%
Output 8Ω：1100W×2
Max 4Ω：1700W×2
Power Bridge 8Ω：3400W
Power：220V 50-60Hz
Shipping Size：600×525×215mm
Net Weight：37Kg |
|
7. BH-403 [2006年9月23日]
 | | | Brand：Harman/Amplifier/BH Series |
Nominal impedance：10KΩ-20KΩ
Frequency response：20Hz-20KHz
Sensitivity：1V
S/N(wide Band Width)：≥95dB
IMD(rated power)：0.05%
Output 8Ω：830W×2
Max 4Ω：1250W×2
Power Bridge 8Ω：2500W
Power：220V 50-60Hz
Shipping Size：600×525×215mm
Net Weight：34Kg |
|
8. BH-302 [2006年9月23日]
 | | | Brand：Harman/Amplifier/BH Series |
Nominal impedance：10KΩ-20KΩ
Frequency response：20Hz-20KHz
Sensitivity：1V
S/N(wide Band Width)：≥90dB
IMD(rated power)：0.05%
Output 8Ω：530W×2
Max 4Ω：840W×2
Power Bridge 8Ω：1700W
Power：220V 50-60Hz
Shipping Size：560×530×180mm
Net Weight：22.5Kg |
|
9. BH-202 [2006年9月23日]
 | | | Brand：Harman/Amplifier/BH Series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：1V
S/N(wide Band Width)：≥90dB
IMD(rated power)：0.05%
Output 8Ω：380W×2
Max 4Ω：655W×2
Power Bridge 8Ω：1300W
Power：220V 50-60Hz
Shipping Size：560×530×180mm
Net Weight：20.5Kg |
|
10. HS-1500 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：0.77V/1V/1.47V
S/N(wide Band Width)：≥95dB
IMD(rated power)：≤0.5%
Output 8Ω：650W×2
Max 4Ω：1100W×2
Power Bridge 8Ω：1800W
Power：220V/50-60Hz
Shipping Size：550×500×180mm
Net Weight：22Kg |
|
11. HS-1000 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：0.77V/1V/1.4V
S/N(wide Band Width)：≥90dB
IMD(rated power)：≤0.5%
Output 8Ω：500W×2
Max 4Ω：850W×2
Power Bridge 8Ω：1500W
Power：220V/50-60Hz
Shipping Size：550×500×180mm
Net Weight：20Kg |
|
12. HS-800 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：0.77V/1V/1.4V
S/N(wide Band Width)：≥90dB
IMD(rated power)：≤0.5%
Output 8Ω：400W×2
Max 4Ω：700W×2
Power Bridge 8Ω：1200W
Power：220V/50-60Hz
Shipping Size：550×500×180mm
Net Weight：19.2Kg |
|
13. HS-600 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：0.77V/1V/1.4V
S/N(wide Band Width)：≥90dB
IMD(rated power)：≤0.5%
Output 8Ω：300W×2
Max 4Ω：510W×2
Power Bridge 8Ω：900W
Power：220V/50-60Hz
Shipping Size：550×500×180mm
Net Weight：18Kg |
|
14. HS-400 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ
Frequency response：20Hz-30KHz ±0.5dB
Sensitivity：0.77V/1V/1.4V
S/N(wide Band Width)：≥90dB
IMD(rated power)：≤0.5%
Output 8Ω：2×200W
Max 4Ω：2×256W
Power Bridge 8Ω：600W
Power：220V 50Hz
Shipping Size：435×510×180mm
Net Weight：14Kg |
|
15. HS-200 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：0.77V/1V/1.4V
S/N(wide Band Width)：≥85dB
IMD(rated power)：≤0.5%
Output 8Ω：100W×2
Max 4Ω：170W×2
Power Bridge 8Ω：300W
Power：220V/50-60Hz
Shipping Size：435×510×180mm
Net Weight：12Kg |
|
16. HS-150 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：0.77V/1V/1.4V
S/N(wide Band Width)：≥83dB
IMD(rated power)：≤0.5%
Output 8Ω：75W×2
Max 4Ω：125W×2
Power Bridge 8Ω：180W
Power：220V/50-60Hz
Shipping Size：435×510×180mm
Net Weight：10Kg |
|
17. HS-180 [2006年9月22日]
 | | | Brand：Harman/Amplifier/HS series |
Nominal impedance：20KΩ-10KΩ
Frequency response：20Hz-20KHz
Sensitivity：0.77V/1V/1.4V
S/N(wide Band Width)：≥95dB
IMD(rated power)：≤0.5%
Output 8Ω：200W×2
Max 4Ω：340W×2
Power Bridge 8Ω：600W
Power：220V/50-60Hz
Shipping Size：425×500×105mm
Net Weight：12.5Kg |
|
18. SA-3500 [2006年9月22日]
 | | | Brand：Harman/Amplifier/SA Series |
Nominal impedance：20KΩ
Frequency response：20Hz-20KHz
Sensitivity：0dB
Damping Factor：>1000
Interaction：>80dB
S/N(wide Band Width)：>100dB
IMD(rated power)：<0.05%
Output 8Ω：2×550W
Max 4Ω：2×950W
Power Bridge 8Ω：1600W
Power：AC220±10% 50-60Hz
Shipping Size：518×485×140
Net Weight：26KG
All models in 3U space. Reliable and Durable professional power amplifier.
High efficiency Dual Power Supply.
Unique heat sink system-T-shape construction changes the flaw of one –way tunnel,
intelligent fan start working automatically when the temperature is 70℃, plus
extra large quality extruded aluminum heat sink area ensure an efficient heat
release and prolong the life of amp.
Balanced and Unbalanced connectors. Stereo, Bridged operation modes.
Power-on Delay, Overload, Output Short Circuit, Soft Start, DC Offset Protections.
Different indicators let you be clear at a glance the working states.
Elegant front panel and ergonomic handles. |
|
19. SA-3000 [2006年9月22日]
 | | | Brand：Harman/Amplifier/SA Series |
Nominal impedance：20KΩ
Frequency response：20Hz-20KHz
Sensitivity：0dB
Damping Factor：>1000
Interaction：>80dB
S/N(wide Band Width)：>100dB
IMD(rated power)：<0.05%
Output 8Ω：2×500W
Max 4Ω：2×850W
Power Bridge 8Ω：1400W
Power：AC220V±10% 50-60Hz
Shipping Size：518×485×140
Net Weight：25.5Kg
All models in 3U space. Reliable and Durable professional power amplifier.
High efficiency Dual Power Supply.
Unique heat sink system-T-shape construction changes the flaw of one –way tunnel,
intelligent fan start working automatically when the temperature is 70℃, plus
extra large quality extruded aluminum heat sink area ensure an efficient heat
release and prolong the life of amp.
Balanced and Unbalanced connectors. Stereo, Bridged operation modes.
Power-on Delay, Overload, Output Short Circuit, Soft Start, DC Offset Protections.
Different indicators let you be clear at a glance the working states.
Elegant front panel and ergonomic handles. |
|
20. SA-2500 [2006年9月22日]
 | | | Brand：Harman/Amplifier/SA Series |
Nominal impedance：20KΩ
Frequency response：20Hz-20KHz
Sensitivity：0dB
Damping Factor：>1000
Interaction：>80dB
S/N(wide Band Width)：>100dB
IMD(rated power)：<0.05%
Output 8Ω：2×400W
Max Ω4：2×750W
Power Bridge 8Ω：1300W
Power：AC220V±10% 50-60Hz
Shipping Size：478×485×140
Net Weight：25Kg
All models in 3U space. Reliable and Durable professional power amplifier.
High efficiency Dual Power Supply.
Unique heat sink system-T-shape construction changes the flaw of one –way tunnel,
intelligent fan start working automatically when the temperature is 70℃, plus
extra large quality extruded aluminum heat sink area ensure an efficient heat
release and prolong the life of amp.
Balanced and Unbalanced connectors. Stereo, Bridged operation modes.
Power-on Delay, Overload, Output Short Circuit, Soft Start, DC Offset Protections.
Different indicators let you be clear at a glance the working states.
Elegant front panel and ergonomic handles. |
|
|
| |
|
|
|
|
