 | | | Brand：Kidrock/Signal Processors/Sequence Controller |
Shipping Size：590×710×180mm
Gross Weight：17Kg
Input Voltage：200-400V/350-450V
Output Voltage：200/240V
Max Output Current： CH1, 2, 3: 3×3×10A ，CH4-CH8: 5×32A
Phase Relation ：A; CH1, 2, 3 ，B; CH4, 5 ，C; CH6, 7, 8
Total Output Current：3×63A
Output Channel：8
Delay Caused By Output：8×1s
Power Consumption：≤30W |
|
 | | | Brand：Kidrock/Signal Processors/Sequence Controller |
Shipping Size：590×710×180mm
Gross Weight：16Kg
Input Voltage：200-400V/350-450V
Output Voltage：200/240V
Max Output Current： CH1, 2, 3: 3×3×10A ，CH4-CH8: 5×32A
Phase Relation ：A; CH1, 2, 3 ，B; CH4, 5 ，C; CH6, 7, 8
Total Output Current：3×63A
Output Channel：8
Delay Caused By Output：8×1s
Power Consumption：≤30W |
|
 | | | Brand：Kidrock/Signal Processors/Sequence Controller |
Shipping Size：610×510×170mm
Gross Weight：12Kg
Input Voltage：200-400V/350-450V
Output Voltage：200V/240V
Max Output Current：CH1\2\3: 5×10A，CH4\5: 2×15A，CH6\7\8: 3×32A
Phase Relation：A;CH1, 2, 3，B;CH4, 5，C;CH6, 7, 8
Total Output Current：3×32A
Output Channel：8
Delay Caused By Output：8×1s
Power Consumption：≤30W |
|
 | | | Brand：Kidrock/Signal Processors/Sequence Controller |
Shipping Size：610×510×170mm
Gross Weight：11Kg
Input Voltage：200-400V/350-450V
Output Voltage：200V/240V
Max Output Current：CH1\2\3: 5×10A，CH4\5: 2×15A，CH6\7\8: 3×32A
Phase Relation：A;CH1, 2, 3，B;CH4, 5，C;CH6, 7, 8
Total Output Current：3×32A
Output Channel：8
Delay Caused By Output：8×1s
Power Consumption：≤30W |
|
 | | | Brand：Kidrock/Signal Processors/Sequence Controller |
Shipping Size：430×520×180mm
Gross Weight：9Kg
|
|
|
|
|
